Overview

SQL Server Database Mail is Microsoft’s recommended solution for sending email notifications directly from SQL Server using SMTP.

Database Mail is widely used for:

• SQL Server Agent Job Notifications
• Backup Success/Failure Alerts
• Database Health Check Reports
• Monitoring Alerts
• Capacity Planning Reports
• Availability Group Notifications
• Custom DBA Reports
• Maintenance Plan Alerts

Prerequisites

1. Enable Database Mail XPs

USE master;
GO
EXEC sp_configure 'show advanced options',1;
GO
RECONFIGURE;
GO
EXEC sp_configure 'Database Mail XPs',1;
GO
RECONFIGURE;
GO

2. Verify Database Mail XPs

SELECT
       name,
       value_in_use
FROM sys.configurations
WHERE name = 'Database Mail XPs';

3. Verify SMTP Connectivity

Test-NetConnection smtp.company.com -Port 25

Expected Result:

TcpTestSucceeded : True

4. Information Required from Messaging Team

Database Mail Configuration

Step 1 – Create Mail Profile

EXEC msdb.dbo.sysmail_add_profile_sp
     @profile_name = 'DBAActivity',
     @description = 'Profile for Automated DBA Notifications';
GO

Step 2 – Create Mail Account

EXEC msdb.dbo.sysmail_add_account_sp
    @account_name = 'DBAActivity',
    @description = 'Account for DBA Notifications',
    @email_address = 'DBAAlert@company.com',
    @display_name = 'SQL DBA Alert',
    @mailserver_name = 'smtp.company.com';
GO

SMTP Authentication Example

EXEC msdb.dbo.sysmail_add_account_sp
    @account_name = 'DBAActivity',
    @email_address = 'DBAAlert@company.com',
    @display_name = 'SQL DBA Alert',
    @mailserver_name = 'smtp.company.com',
    @port = 587,
    @enable_ssl = 1,
    @username = 'DBAAlert',
    @password = 'Password';
GO

Step 3 – Associate Profile and Account

EXEC msdb.dbo.sysmail_add_profileaccount_sp
     @profile_name = 'DBAActivity',
     @account_name = 'DBAActivity',
     @sequence_number = 1;
GO

Step 4 – Set Default Profile

EXEC msdb.dbo.sysmail_add_principalprofile_sp
     @profile_name = 'DBAActivity',
     @principal_name = 'public',
     @is_default = 1;
GO

Step 5 – Restart Database Mail

EXEC msdb.dbo.sysmail_stop_sp;
GO

EXEC msdb.dbo.sysmail_start_sp;
GO

Step 6 – Send Test Email

EXEC msdb.dbo.sp_send_dbmail
     @recipients = 'dbateam@company.com',
     @subject = 'Database Mail Test',
     @body = 'Database Mail configuration completed successfully.';
GO

SQL Server Agent Configuration

Verify SQL Agent Mail Settings

EXEC msdb.dbo.sp_get_sqlagent_properties;
GO

Configure SQL Agent to Use Database Mail

EXEC msdb.dbo.sp_set_sqlagent_properties
     @databasemail_profile = 'DBAActivity',
     @use_databasemail = 1;
GO

SQL Server Agent Operator Configuration

Create Operator

USE msdb;
GO
EXEC dbo.sp_add_operator
     @name = N'DBA Team',
     @enabled = 1,
     @email_address = N'dbateam@company.com';
GO

Verify Operator

SELECT
       name,
       enabled,
       email_address
FROM msdb.dbo.sysoperators;
GO

Configure Job Notifications

EXEC msdb.dbo.sp_update_job
     @job_name = 'Database Backup',
     @notify_email_operator_name = 'DBA Team',
     @notify_level_email = 2;
GO

Validation Queries

Database Mail Status

EXEC msdb.dbo.sysmail_help_status_sp;
GO

Expected:

STARTED

Check Sent Emails

SELECT
    send_request_date,
    sent_date,
    sent_status,
    recipients,
    subject
FROM msdb.dbo.sysmail_allitems
ORDER BY send_request_date DESC;
GO

Check Failed Emails

SELECT *
FROM msdb.dbo.sysmail_allitems
WHERE sent_status = 'failed'
ORDER BY send_request_date DESC;
GO

Review Database Mail Event Log

SELECT
    log_date,
    event_type,
    description
FROM msdb.dbo.sysmail_event_log
ORDER BY log_date DESC;
GO

Maintenance & Cleanup

Purge Mail History Older Than 90 Days

EXEC msdb.dbo.sysmail_delete_mailitems_sp
     @sent_before = DATEADD(DAY,-90,GETDATE());
GO

Purge Mail Logs Older Than 90 Days

EXEC msdb.dbo.sysmail_delete_log_sp
     @logged_before = DATEADD(DAY,-90,GETDATE());
GO

Security Best Practices

• Use dedicated service mailboxes.
• Use Distribution Groups instead of individual email accounts.
• Secure SMTP credentials.
• Review failed emails regularly.
• Monitor Database Mail Event Logs.
• Periodically test email notifications.
• Purge old mail history and logs.
• Validate functionality after SQL upgrades and DR failovers.

Operational Best Practices

Configure notifications for:

• Database Backup Jobs
• DBCC CHECKDB Jobs
• Index Maintenance Jobs
• ETL Jobs
• Availability Group Monitoring Jobs
• Replication Jobs
• Log Shipping Jobs
• Custom Monitoring Jobs

Implementation Validation Summary
